Semi-Automatic Peanut Butter Filling Machine is semi-automatic piston filling machine. It use compressed air as power, which is composed of precision pneumatic components. The Peanut Filling machine has the features of simple structure, reliable and convenient adjustment. This Piston Filling Machineis suitable for all kinds of paste, viscous paste filling. This paste filling machine can work in the inflammable and explosive environment. It is the ideal filling equipment of pharmaceutical, chemical, food, cosmetics and other industries.
Feature of Peanut Butter Filling Machine
- Our peanut butter filling machine adopts a plunger piston, and the quantitative filling system adjusts the filling volume and speed with high precision, the measurement accuracy is less than 2%.
- The parts in contact with the peanut butter are made of 316L stainless steel and the piston is made of PTFE material, which meets GMP requirements.
- Semi-automatic piston peanut filling machine supports manual and automatic switching. The filling nozzle can be replaced according to different materials, and it can fill the granular slurry fluid material.
- Equipped with an automatic blender to ensure thorough mixing of peanut butter.
- The filling bulkhead is an anti-drip, anti-drawing and lifting filling device.
- Highly adaptable, quickly adjust and replace bottles for different materials.
- The hopper, stainless steel tee and three-way steering valve are easy to remove and wash.
Specification of Peanut Butter Filling Machine
| Model | RM-PF1 | RM-PF2 |
| Filling Head | One Head | Double Head |
| Filling Speed | 15-20 bottles/min | 30-40 bottles/min |
| Power | can customized | |
| Air Pressure | 0.4MPa-0.6Mpa | |
| Filing Volumes | 5-100ml,10-200ml,50-500ml,100-1000ml,500-2500ml,1000-5000ml | |
Working Video of Peanut Butter Filling Machine
Company Profile
Romiter Machinery Co., Ltd. is a market leading manufacturer of Peanut Processing Machine with 10 years experience. Our factory is company, located at Middle China. Romiter has an excellent technical support team, including highly experienced machinists and service technicians. All our machines is equipped with reliable brand components. This enables us to provide our customers with continuous high quality Peanut processing machine at competitive prices.
Now, Our factory can provide peanut shelling machine, wet type peanut skin peeling machine, dry type peanut skin peeling machine, peanut butter grinder, peanut butter production line, small peanut roaster machine, industrial peanut roasting machine, peanut slicing machine, peanut granule cutting machine, peanut candy making machine, peanut frying machine, peanut flour coating machine , peanut oil pressing machine , peanut size sorting machine and peanut harvester machine.
Welcome to Contact Us for more information
